Volcano High Volume Lake Aerators

The Volcano High Volume Aerator range is expertly designed to enhance oxygenation in large ponds and lakes, covering areas from 4,000 square meters (approximately 1 acre) to 20,000 square meters (about 5 acres). These aerators are renowned for their exceptional oxygen transfer rates, delivering up to 1.5 kg per horsepower hour.

Key Features:

• Power Options: Available in 1HP, 3HP, and 5HP models to suit various water bodies and conditions.
• High Performance: Custom-built, oil-cooled motors achieve flow rates of up to 647,200 liters per hour (approximately 142,300 gallons per hour).
• Durable Construction: Constructed with corrosion-resistant materials like stainless steel and rugged thermoplastics for minimal maintenance and long-lasting performance.
• Impressive Water Displays: Capable of producing water displays ranging from 1.2 meters in diameter by 0.5 meters in height (4 feet by 1.5 feet) to 3.5 meters in diameter by 1.1 meters in height (11.5 feet by 3.5 feet).

Performance Capabilities:

• Depth Versatility: Efficiently aerates water up to 4.5 meters deep while also functioning in shallow water as low as 1 meter (3 feet).
• Floating Design: Allows for easy repositioning to optimize aeration where needed.

Included Equipment:

• 1 x Floating Motor Assembly: Includes a robust thermoplastic float.
• 1 x High Volume Chamber Assembly.

Power Specifications:

• 1HP and 3HP Aerators: Available only in 230V, single-phase power.
• 5HP Aerators: Available only in 400V, three-phase power.

These high-volume aerators are ideal for improving water quality in challenging environments such as brackish water or effluent ponds, offering a powerful and efficient solution for large-scale oxygenation needs.
